We have consulted with Global Engineering Services Ltd to bring you brackets specifically
made to comply with the New Zealand building code.
TBA12
Titan Brace Anchor - Heavy Duty for Heavy Application
Code: TBA12
Materials: 75 x 6.0 Mild Steel Zinc Plated OR
75 x 6.0 304 Stainless Steel
- Fixed with 9 x 12g x 35 type 17 screws and 1 x Anchor
Or limit of MK10 Anchor if less fixing supplies with Brackets
TNP200
Titan Nail Plate
Code: TNP200
Materials: 0.9 G300 Full Spangle Galv OR 1.0 304 2B Stainless Steel. Fixed with 40 x 30 X 3.15 Ø nails. Tension = 37.8 kN. Shear = 27.2 kN.
TWDS
Titan Wire Dog Staples - Stainless Steel ONLY
Code: TWDS
TWDZ
Titan wire dogs (lh & rh) stainless steel only
Code: TWDZ
Materials: Ø 4.76mm SS Wire
TBA6
Titan Brace Anchor
Code: TBA6
Materials: 5.0 mm Mild Steel Zinc Plated OR 5.0 304 Stainless Steel - Fixed with 7 x 12g x 35 Type 17 Screws and 1 x M10 x 140 Screwbolt or Anchor Or Limit of M10 Anchor if less fixings supplied with Brackets
TFW
Titan Flat Washer
Code: TFW
TPC215
Titan Purlin Cleat 215
Code: TPC215
Materials: 0.9 G300 Full Spangle Galv OR 1.0 304 2B Stainless Steel. Fixed width with 30 X 3.15 Ø nails. 2 Nails each end - 3.0 kN. 3 Nails each end - 4.5 kN. 4 Nails each end - 6.0 kN. 5 Nails each end - 7.5 kN.
TCPC85
Titan Concealed Purlin Cleat
Code: TCPC85
Materials: 1.6 G300 Full Spangle Galv or 1.6 304 2B Stainless Steel
Fixed with 8 x 30 X 3.15 Ø nails and 4 x 12g X 35 type 17 screws 6kN - Also available in different lengths and material gauges.
THWT600
High Wind Ties
Code: THWT600
Materials: Materials: 0.9 G300 Full Spangle Galv OR 1.0 304 2B Stainless Steel Fixed with 30 x 3.15 Ø nails 3 nails each end - 4.5 kN. 4 nails each end - 6.0 kN. 5 nails each end - 7.5 kN.
TSBS600
Titan Sheet Brace Straps
Code: TSBS600
Materials: 0.9 G300 Full Spangle Galv OR
1.0 304 2B Stainless Steel
Using 30 x 3.15 Ø nails 8 nails both ends 6 kN
